Ins, Outs, and Switches

• High impedance ultra low-noise discrete Class A JFET TRS stereo input
• Low impedance independent TS stereo outputs.
• Expression pedal input allows the connection of a TRS expression pedal, MiniSwitch, MultiSwitch Plus, or TRS MIDI connection.
• USB jack for controlling via MIDI from a computer or for performing firmware updates.
• Dedicated Favorite On/Off footswitches



Audio Quality

• Premium JFET analog front end
• Ultra low noise, high performance 24-bit 96kHz A/D and D/A converters provide uncompromising audio quality
• 520MHz ARM Superscalar processor
• 32-bit floating point processing
• 20Hz to 20kHz frequency response
• Audio Input Impedance: 1M Ohm
• Audio Output Impedance: 100 Ohm

More

• Strong and lightweight pink aluminum chassis
• 9V DC power supply (Not included)
• Power requirements: maximum 9 volts DC center-negative, with a minimum of 300mA of current
• Dimensions : 11.4 cm deep x 10.2 cm wide x 4.4 cm tall
• Designed and built in the USA
