Sound Design

• Hand crafted, studio-class reverb algorithms deliver lush, gorgeous, and musically inspiring reverb experiences
• Twelve reverb machines to choose from: Room, Hall, Plate, Spring, Swell, Bloom, Cloud, Chorale, Shimmer, Magneto, Nonlinear, Reflections
• Seven front-panel tone shaping knobs: Decay, Pre-Delay, Mix, Tone, Mod, Param 1, Param 2 (Param knobs assignable per preset)
• Additional menu parameters allow for easy customization of reverb sounds
300 easily accessible and namable presets
• Press-and-hold Infinite Sustain and Freeze functions, saveable per preset
• Spillover and Reverb Persist modes, saveable per preset
• Selectable Speaker Cabinet emulation for direct-to-PA gigs or recording applications

Ins, Outs

• Stereo input and output
• Expression pedal input with selectable control over any knob or combination of knobs, saveable per preset (also configurable as external tap input)
• MIDI input and output
• Included 9V center-negative power supply (300mA minimum required)



Audio Quality

• Analog dry path for a zero latency dry signal that is never converted to digital
• Premium analog front end and output section
• Ultra low noise, high performance 24-bit 96kHz A/D and D/A converters
• 115dB typical signal to noise at 50% wet mix (120db at 100% dry mix, 109dB at 100% wet mix)
• 20Hz to 20kHz frequency response
• +8dBu maximum input level easily handles instrument and line signals

Processor

• Super high performance DSP in a compact form factor
• 32-bit floating point processing
• 366MHz SIMD SHARC processor core, capable of 2.4 Gigaflops peak performance



Hardware

• Three rugged metal footswitches for preset selection and effect bypass
• LED display for preset info, reverb decay time, and extended parameter control
• Multi-color preset LEDs (green for active preset, amber for edited preset)
• Full MIDI implementation allows extended control for those with more complex rigs
• Sturdy and lightweight light blue anodized aluminum chassis, with laser-etched artwork
• Durable black anodized aluminum knobs
• Studio-grade audio input and output jacks

More

• True Bypass (electromechanical relay switching)
• High quality, tranparent Analog Buffered Bypass mode
• +/- 3dB Boost/Cut, saveable per preset
• Optional Kill Dry mode mutes dry signal, for use in parallel effects loops
• Dimensions: 6.75″ (171mm) wide, 5.1″ (130mm) deep
• Designed and Built in the USA
